Operating Specifications

• Operation Pressure:150 psi(10.5 Bar)
• Operating Temperature:34·120°F(1-49℃)
• Max Vacuum:5" Hg(127mm Hg)
• Lowest exposed Temperature:-17°F(-27℃)

Testing parameters

• Exceed 100,000 times of cycle test from 0-150psi with standing pressure

• Burst test to 4 times(600psi) of its operating pressure
