Sand gravel separator for concrete batching plant
- PRODUCT DETAIL
Packaging & Delivery
| Quantity(Set) | 1 - 3 | >3 |
| Est. Time(day) | 30 | To be negotiated |
Concrete sand gravel separator.
The water content of the separated stone is < 1%, ash content is < 1%, and the surface is clean.
The water content of separated sand is 3-5%.Ash content < 1%.
|
Model |
Screening ability |
Total weight |
Sands size (mm) |
Appearance size L*W*H (mm) |
Whole machine power (KW) |
Quantity of concrete mixer truck |
|
DH120-I (Singleparking) |
15-25 t/h |
3100KG |
Diameter 1-7 |
4500*1800*1750 (mainframe) |
11.5(Include pump) |
≤30 SETS |
|
DH120-II (Double parking) |
20-40 t/h |
3800KG |
Diameter 1-7 |
4500*1800*1750 (mainframe) |
17(Include pump) |
≤50 SETS |
